Pagid 355116182 - Disc Brake Rotor, Externally Vented, Diameter: 328 mm, Thickness 30.0 mm, 328 mm

Pagid 355116182 - Disc Brake Rotor, Externally Vented, Diameter: 328 mm, Thickness 30.0 mm
Actual Product may vary from pictures due to Vehicle Fitment.
Zoom image

Pagid 355116182 - Disc Brake Rotor, Externally Vented, Diameter: 328 mm, Thickness 30.0 mm, 328 mm

Part No: 355116182
Not in Stock

Please call 888-257-7149 to check future availability

  • $135.70 & FREE Shipping

Starting at $XX/mo with Affirm. Prequalify now

Pagid 355116182 - Disc Brake Rotor, Externally Vented, Diameter: 328 mm, Thickness 30.0 mm, 328 mm

FMXC-355116182
Not in Stock

Please call 888-257-7149 to check future availability

  • $135.70 & FREE Shipping

Starting at $XX/mo with Affirm. Prequalify now

Vehicle Specific

Specs and ratings

Stopping Power:




Noise Level:




Performance Over Stock:




  • Full range is 100% high carbon (GG15 & GG20)
  • Less fading and quiet braking
  • Reduced braking noise
  • Fixing screws are always included if required
  • Manufactured according to European OE specifications (AM1 & AM2)
  • Increased carbon content for increased heat conductivity and better mechanical properties
  • Full range is 100% fully coated with premium zinc rust protection
Check All Vehicles this Part Fits

Product details

 Description

Disc Brake Rotor
Disc Brake Rotor

 Specifications

Package
  • Brand
    Pagid,  Pagid Brake Rotors
  • Part Number
    355116182
  • UPC
    4082300691917
  • Height
    2.76 in
  • Width
    13.78 in
  • Length
    14.37 in
  • Weight
    27.902 lbs
Attributes
  • Driving Qualifiers
    Normal Commute, Performance Street
  • Rotor Style
    Smooth-Plain
  • Stopping Power
    3 / 5
  • Noise Level
    2 / 5
  • Performance Over Stock
    0 - Basic Commute, 2 - Performance/Commuter, 3 - Street Performance
Details
  • Part Name
    Disc Brake Rotor
  • ABS Tone Ring Included
    No
  • Assy/Disassy by Qualified Personnel Required!
    .
  • Balancing Type
    Mill Balancing
  • Bearings Included
    No
  • Bolt Hole Circle Ø [in]
    4.25
  • Bolt Hole Circle Ø [mm]
    108
  • Brake Disc Thickness [in]
    1.18
  • Brake Disc Thickness [mm]
    30
  • Brake Disc Type
    Externally Vented
  • Center Hole Diameter
    108.0
  • Centering Diameter [mm]
    63.6
  • Construction
    Full Cast
  • Directional or Non-Directional Brake Surface
    Non-Directional
  • Disc Finish
    coated
  • Discard Thickness
    28.00 mm
  • Grade Type
    Standard Replacement
  • Hat Finish
    coated
  • Height [mm]
    52.1
  • Hole Arrangement/Number
    05/06
  • Inner Diameter [in]
    5.51
  • Inner diameter [mm]
    140
  • Inside Diameter
    63.6
  • Machining
    High-Carbon
  • Material
    gray cast iron
  • Minimum thickness [in]
    1.10
  • Minimum thickness [mm]
    28
  • Mounting Bolt Hole Circle Diameter
    108.00 mm
  • Mounting Bolt Hole Quantity
    6
  • Nominal Thickness
    30.00 mm
  • Outer Diameter [in]
    12.91
  • Outer diameter [mm]
    328
  • Outside Diameter
    328.00 mm
  • Overall Height
    52.10 mm
  • Rust Resistant Coating
    Yes
  • Solid Or Vented Type Rotor
    Vented
  • Supplementary Article/Info 2
    without Wheel Hub
  • Surface
    Coated
  • Surface Type
    Smooth
  • Technical Information Number
    54963PRO_HC_NA
  • Wheel Bolt Bore Diameter [mm]
    15.7
  • Wheel Bolt Bore Ø [mm]
    15.7
Manufacturer description
  • Manufacturer Label
    Integral One-Piece Design

 Fast Shipping and Easy Returns


Customer satisfaction is our top priority. We want to ensure your experience with BuyBrakes.com is the best it can possibly be. If you're unsatisfied with your order and wish to return it, please follow our guidelines below.

Compatible with the following vehicles

Model Engine Trim Notes
2015, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S5, 95 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S5, 95 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S4, 94 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S4, 94 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 2.5, 2521, L, 5 T5 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 2.5, 2521, L, 5 T5 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 2.0, 1969, L, 4 T5 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 2.0, 1969, L, 4 T5 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 3.0, 2953, L, 6 T6 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 3.0, 2953, L, 6 T6 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 2.0, 1969, L, 4 T6 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 2.0, 1969, L, 4 T6 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 3.0, 2953, L, 6 T6 Ocean Race Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 3.0, 2953, L, 6 T6 Ocean Race Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 2.0, 1969, L, 4 T6 Ocean Race, 49 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 2.0, 1969, L, 4 T6 Ocean Race, 49 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 T6 R-Design Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Volvo XC60 T6 R-Design Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2014, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S5, 95 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2014, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S5, 95 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2014, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S4, 94 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2014, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S4, 94 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2014, Volvo XC60 T6 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2014, Volvo XC60 T6 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2014, Volvo XC60 T6 R-Design Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2014, Volvo XC60 T6 R-Design Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2013, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S5, 95 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2013, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S5, 95 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2013, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S4, 94 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2013, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S4, 94 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2013, Volvo XC60 T6 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2013, Volvo XC60 T6 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2013, Volvo XC60 3.0, 2953, L, 6 T6 R-Design Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2013, Volvo XC60 3.0, 2953, L, 6 T6 R-Design Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2012, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S5, 95 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2012, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S5, 95 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2012, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S4, 94 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2012, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S4, 94 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2012, Volvo XC60 T6 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2012, Volvo XC60 T6 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2012, Volvo XC60 T6 R-Design Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2012, Volvo XC60 T6 R-Design Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2011, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S5, 95 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2011, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S5, 95 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2011, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S4, 94 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2011, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S4, 94 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2011, Volvo XC60 3.2, 3192, L, 6 3.2 R-Design, B6324S5, 95 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2011, Volvo XC60 3.2, 3192, L, 6 3.2 R-Design, B6324S5, 95 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2011, Volvo XC60 3.2, 3192, L, 6 3.2 R-Design, B6324S4, 94 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2011, Volvo XC60 3.2, 3192, L, 6 3.2 R-Design, B6324S4, 94 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2011, Volvo XC60 T6 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2011, Volvo XC60 T6 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2011, Volvo XC60 T6 R-Design Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2011, Volvo XC60 T6 R-Design Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2010, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S, 98 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2010, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S, 98 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2010, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S2, 96 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2010, Volvo XC60 3.2, 3192, L, 6 3.2, B6324S2, 96 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2010, Volvo XC60 T6 Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2010, Volvo XC60 T6 Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
2010, Volvo XC60 T6 R-Design Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2010, Volvo XC60 T6 R-Design Front, Qty - 2, Designed and Engineered in Germany;High Carbon - Fully Coated
