Pagid 355109432 - Disc Brake Rotor, Internally Vented, Diameter: 330 mm, Thickness 32.0 mm, 330 mm

Previous image
Pagid 355109432 - Disc Brake Rotor, Internally Vented, Diameter: 330 mm, Thickness 32.0 mm
Actual Product may vary from pictures due to Vehicle Fitment.
Next image
Zoom image

Pagid 355109432 - Disc Brake Rotor, Internally Vented, Diameter: 330 mm, Thickness 32.0 mm, 330 mm

Part No: 355109432
In Stock Arrives: Jun 29 - Jul 3
  • $129.07 & FREE Shipping

Starting at $XX/mo with Affirm. Prequalify now

Pagid 355109432 - Disc Brake Rotor, Internally Vented, Diameter: 330 mm, Thickness 32.0 mm, 330 mm

FMXC-355109432
In Stock Arrives: Jun 29 - Jul 3
  • $129.07 & FREE Shipping

Starting at $XX/mo with Affirm. Prequalify now

Vehicle Specific

Specs and ratings

Stopping Power:




Noise Level:




Performance Over Stock:




  • Manufactured according to European OE specifications (AM1 & AM2)
  • Full range is 100% high carbon (GG15 & GG20)
  • Improved aesthetics and appearance of brake discs, especially when used with aluminum rims
  • Higher driving comfort with reduced machining tolerances
  • Less fading and quiet braking
  • Fixing screws are always included if required
  • Reduced braking noise
Check All Vehicles this Part Fits

Product details

 Description

Disc Brake Rotor
DISC BRAKE ROTOR

 Specifications

Package
  • Brand
    Pagid,  Pagid Brake Rotors
  • Part Number
    355109432
  • UPC
    4082300573299
  • Height
    3.35 in
  • Width
    14.76 in
  • Length
    15.35 in
  • Weight
    25.21 lbs
Attributes
  • Driving Qualifiers
    Normal Commute, Performance Street
  • Rotor Style
    Smooth-Plain
  • Stopping Power
    3 / 5
  • Noise Level
    2 / 5
  • Performance Over Stock
    0 - Basic Commute, 2 - Performance/Commuter, 3 - Street Performance
Details
  • Part Name
    Disc Brake Rotor
  • ABS Tone Ring Included
    No
  • Assy/Disassy by Qualified Personnel Required!
    .
  • Balancing Type
    Mill Balancing
  • Bearings Included
    No
  • Bolt Hole Circle Ø [in]
    4.41
  • Bolt Hole Circle Ø [mm]
    112
  • Brake Disc Thickness [in]
    1.26
  • Brake Disc Thickness [mm]
    32
  • Brake Disc Type
    Internally Vented
  • Center Hole Diameter
    112.0
  • Centering Diameter [in]
    2.64
  • Centering Diameter [mm]
    67
  • Color
    Silver
  • Construction
    Full Cast
  • Directional or Non-Directional Brake Surface
    Non-Directional
  • Disc Finish
    coated
  • Discard Thickness
    29.40 mm
  • Grade Type
    Standard Replacement
  • Hat Finish
    coated
  • Height [mm]
    64.4
  • Hole Arrangement/Number
    05/06
  • Inner diameter [mm]
    154.4
  • Inside Diameter
    67.0
  • Machining
    High-Carbon
  • Material
    gray cast iron
  • Minimum thickness [mm]
    29.4
  • Mounting Bolt Hole Circle Diameter
    112.00 mm
  • Mounting Bolt Hole Quantity
    6
  • Nominal Thickness
    32.00 mm
  • Number of bolts/screws
    1
  • Outer Diameter [in]
    12.99
  • Outer diameter [mm]
    330
  • Outside Diameter
    330.00 mm
  • Overall Height
    64.40 mm
  • Rust Resistant Coating
    Yes
  • Solid Or Vented Type Rotor
    Vented
  • Supplementary Article/Info 2
    without Wheel Studs
  • Surface
    Coated
  • Surface Type
    Smooth
  • Technical Information Number
    54199PRO_HC_NA
  • Wheel Bolt Bore Diameter [mm]
    15.3
  • Wheel Bolt Bore Ø [mm]
    15.3
Manufacturer description
  • Manufacturer Label
    Integral One-Piece Design

 Fast Shipping and Easy Returns


Customer satisfaction is our top priority. We want to ensure your experience with BuyBrakes.com is the best it can possibly be. If you're unsatisfied with your order and wish to return it, please follow our guidelines below.

Compatible with the following vehicles

Model Engine Trim Notes
2015, Mercedes-Benz GLK250 Bluetec 4Matic Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Mercedes-Benz GLK350 4Matic Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2015, Mercedes-Benz GLK350 Base Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2014, Mercedes-Benz GLK250 Bluetec 4Matic Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2014, Mercedes-Benz GLK350 4Matic Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2014, Mercedes-Benz GLK350 Base Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2013, Mercedes-Benz GLK250 Bluetec 4Matic Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2013, Mercedes-Benz GLK350 4Matic Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2013, Mercedes-Benz GLK350 Base Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2012, Mercedes-Benz GLK350 4Matic Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2012, Mercedes-Benz GLK350 Base Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2011, Mercedes-Benz CLS550 Base Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2011, Mercedes-Benz GLK350 4Matic Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2011, Mercedes-Benz GLK350 Base Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2010, Mercedes-Benz CLS550 Base Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2010, Mercedes-Benz GLK350 4Matic Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2010, Mercedes-Benz GLK350 Base Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2009, Mercedes-Benz CLS550 Base Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2009, Mercedes-Benz E550 Base Front, Qty - 2, Exc.Sport Package;High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2008, Mercedes-Benz CLS550 Base Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2008, Mercedes-Benz E550 Base Front, Qty - 2, Exc.Sport Package;High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2007, Mercedes-Benz CLS550 Base Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2007, Mercedes-Benz E550 Base Front, Qty - 2, Exc.Sport Package;High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
2006, Mercedes-Benz CLS500 Base Front, Qty - 2, High Carbon, Fully Coated;Designed and Engineered in Germany;High Carbon - Fully Coated
