Pagid 355107562 - Disc Brake Rotor, Solid, Diameter: 255 mm, Thickness 11.9 mm, 255 mm

Previous image
Pagid 355107562 - Disc Brake Rotor, Solid, Diameter: 255 mm, Thickness 11.9 mm
Actual Product may vary from pictures due to Vehicle Fitment.
Next image
Zoom image

Pagid 355107562 - Disc Brake Rotor, Solid, Diameter: 255 mm, Thickness 11.9 mm, 255 mm

Part No: 355107562
In Stock Arrives: Jul 21 - 27
  • $47.03

Pagid 355107562 - Disc Brake Rotor, Solid, Diameter: 255 mm, Thickness 11.9 mm, 255 mm

FMXC-355107562
In Stock Arrives: Jul 21 - 27
  • $47.03
Vehicle Specific

Specs and ratings

Stopping Power:




Noise Level:




Performance Over Stock:




  • Full range is 100% high carbon (GG15 & GG20)
  • Less fading and quiet braking
  • Fixing screws are always included if required
  • Increased carbon content for increased heat conductivity and better mechanical properties
  • Not oiled, no degreasing from preservative oil before fitting, saving time and money in the workshop
  • Reduced braking noise
  • Manufactured according to European OE specifications (AM1 & AM2)
Check All Vehicles this Part Fits

Product details

 Description

Disc Brake Rotor
DISC BRAKE ROTOR

 Specifications

Package
  • Brand
    Pagid,  Pagid Brake Rotors
  • Part Number
    355107562
  • UPC
    4082300572117
  • Height
    2.76 in
  • Width
    11.02 in
  • Length
    11.61 in
  • Weight
    9.436 lbs
Attributes
  • Driving Qualifiers
    Normal Commute, Performance Street
  • Rotor Style
    Smooth-Plain
  • Stopping Power
    3 / 5
  • Noise Level
    2 / 5
  • Performance Over Stock
    0 - Basic Commute, 2 - Performance/Commuter, 3 - Street Performance
Details
  • Part Name
    Disc Brake Rotor
  • ABS Tone Ring Included
    No
  • Assy/Disassy by Qualified Personnel Required!
    .
  • Balancing Type
    Mill Balancing
  • Bearings Included
    No
  • Bolt Hole Circle Ø [in]
    4.41
  • Bolt Hole Circle Ø [mm]
    112
  • Brake Disc Thickness [mm]
    11.9
  • Brake Disc Type
    Solid
  • Center Hole Diameter
    112.0
  • Centering Diameter [in]
    2.68
  • Centering Diameter [mm]
    68
  • Color
    Silver
  • Construction
    Full Cast
  • Directional or Non-Directional Brake Surface
    Non-Directional
  • Disc Finish
    coated
  • Discard Thickness
    10.00 mm
  • Grade Type
    Standard Replacement
  • Hat Finish
    coated
  • Height [mm]
    39.9
  • Hole Arrangement/Number
    05/10
  • Inner diameter [mm]
    142.7
  • Inside Diameter
    68.0
  • Machining
    High-Carbon
  • Material
    gray cast iron
  • Minimum thickness [in]
    0.39
  • Minimum thickness [mm]
    10
  • Mounting Bolt Hole Circle Diameter
    112.00 mm
  • Mounting Bolt Hole Quantity
    10
  • Nominal Thickness
    11.90 mm
  • Outer Diameter [in]
    10.04
  • Outer diameter [mm]
    255
  • Outside Diameter
    255.00 mm
  • Overall Height
    39.90 mm
  • Rust Resistant Coating
    Yes
  • Solid Or Vented Type Rotor
    Solid
  • Supplementary Article/Info 2
    without Wheel Hub
  • Surface
    Coated
  • Surface Type
    Smooth
  • Technical Information Number
    50312PRO_HC_NA
  • Wheel Bolt Bore Diameter [mm]
    15.5
  • Wheel Bolt Bore Ø [mm]
    15.5
Manufacturer description
  • Manufacturer Label
    Integral One-Piece Design

 Fast Shipping and Easy Returns


Customer satisfaction is our top priority. We want to ensure your experience with BuyBrakes.com is the best it can possibly be. If you're unsatisfied with your order and wish to return it, please follow our guidelines below.

Compatible with the following vehicles

Model Engine Trim Notes
2006, Audi A4 Cabriolet Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2006, Audi A4 Quattro Cabriolet Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 3.0, 2976, V, 6 Base Rear, Qty - 2, From Chassis/VIN 8E-5-060 001;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 3.0, 2976, V, 6 Base Rear, Qty - 2, To Chassis/VIN 8E-5-060 000;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 1.8, 1781, L, 4 Base Rear, Qty - 2, From Chassis/VIN 8H-5-006 501;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 1.8, 1781, L, 4 Base Rear, Qty - 2, To Chassis/VIN 8H-5-006 500;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 3.0, 2976, V, 6 Cabriolet Rear, Qty - 2, To Chassis/VIN 8H-5-006 500;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 3.0, 2976, V, 6 Cabriolet Rear, Qty - 2, From Chassis/VIN 8H-5-006 501;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 1.8, 1781, L, 4 Cabriolet Rear, Qty - 2, From Chassis/VIN 8H-5-006 501;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 1.8, 1781, L, 4 Cabriolet Rear, Qty - 2, To Chassis/VIN 8H-5-006 500;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 Quattro 3.0, 2976, V, 6 Avant Rear, Qty - 2, To Chassis/VIN 8E-5-060 000;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 Quattro 3.0, 2976, V, 6 Avant Rear, Qty - 2, From Chassis/VIN 8E-5-060 001;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 Quattro 1.8, 1781, L, 4 Avant Rear, Qty - 2, To Chassis/VIN 8E-5-060 000;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 Quattro 1.8, 1781, L, 4 Avant Rear, Qty - 2, From Chassis/VIN 8E-5-060 001;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 Quattro 3.0, 2976, V, 6 Base Rear, Qty - 2, To Chassis/VIN 8E-5-060 000;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 Quattro 3.0, 2976, V, 6 Base Rear, Qty - 2, From Chassis/VIN 8E-5-060 001;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 Quattro 1.8, 1781, L, 4 Base Rear, Qty - 2, To Chassis/VIN 8E-5-060 000;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 Quattro 1.8, 1781, L, 4 Base Rear, Qty - 2, From Chassis/VIN 8E-5-060 001;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 Quattro Cabriolet Rear, Qty - 2, From Chassis/VIN 8H-5-006 501;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2005, Audi A4 Quattro Cabriolet Rear, Qty - 2, To Chassis/VIN 8H-5-006 500;High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2004, Audi A4 3.0, 2976, V, 6 Base Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2004, Audi A4 1.8, 1781, L, 4 Base Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2004, Audi A4 3.0, 2976, V, 6 Cabriolet Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2004, Audi A4 1.8, 1781, L, 4 Cabriolet Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2004, Audi A4 Quattro 3.0, 2976, V, 6 Avant Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2004, Audi A4 Quattro 1.8, 1781, L, 4 Avant Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2004, Audi A4 Quattro 3.0, 2976, V, 6 Base Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2004, Audi A4 Quattro 1.8, 1781, L, 4 Base Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2004, Audi A4 Quattro Cabriolet Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2003, Audi A4 3.0, 2976, V, 6 Base Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2003, Audi A4 1.8, 1781, L, 4 Base Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2003, Audi A4 3.0, 2976, V, 6 Cabriolet Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2003, Audi A4 1.8, 1781, L, 4 Cabriolet Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2003, Audi A4 Quattro 3.0, 2976, V, 6 Avant Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2003, Audi A4 Quattro 1.8, 1781, L, 4 Avant Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2003, Audi A4 Quattro 3.0, 2976, V, 6 Base Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2003, Audi A4 Quattro 1.8, 1781, L, 4 Base Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2002, Audi A4 3.0, 2976, V, 6 Base Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2002, Audi A4 1.8, 1781, L, 4 Base Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2002, Audi A4 Quattro 3.0, 2976, V, 6 Avant Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2002, Audi A4 Quattro 1.8, 1781, L, 4 Avant Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2002, Audi A4 Quattro 3.0, 2976, V, 6 Base Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
2002, Audi A4 Quattro 1.8, 1781, L, 4 Base Rear, Qty - 2, High Carbon, Fully Coated;255mm Dia.;Designed and Engineered in Germany;High Carbon - Fully Coated
