Bilstein 47-265417 - Suspension Kit

Previous image
Bilstein 47-265417 - Suspension Kit
Actual Product may vary from pictures due to Vehicle Fitment.
Next image
Zoom image

Bilstein 47-265417 - Suspension Kit

Part No: 47-265417
Out of Stock

Please call 888-257-7149 to check future availability

  • $1196.00 & FREE Shipping
List: $1677.00

Starting at $XX/mo with Affirm. Prequalify now

Bilstein 47-265417 - Suspension Kit

BBGL-47-265417
Out of Stock

Please call 888-257-7149 to check future availability

  • $1196.00 & FREE Shipping
List: $1677.00

Starting at $XX/mo with Affirm. Prequalify now

Vehicle Specific
  • Threaded body allows lowering of approximately 30mm to 50mm
  • Tested by our engineers under motorsport conditions
  • Triple-C-Technology surface coating for long lasting corrosion resistance
Check All Vehicles this Part Fits

Product details

 Description

Performance Suspension System
Bilstein B14 (PSS) suspension kits feature ride height adjustability in an OE quality, direct fit package. These kits offer monotube performance dampers with matched springs that are tuned for each specific application. The zinc coated and threaded body design will give you the flexibility to find the perfect ride height setting for your intended use while providing unsurpassed protection against the harshest road elements. B14 (PSS) suspension kits are made in Germany and feature technology tested on the famed Nürburgring.

 Specifications

Package
  • Brand
    Bilstein,  Bilstein Suspension
  • Part Number
    47-265417
  • UPC
    651860804729
  • Height
    8.3 in
  • Width
    11. in
  • Length
    30.3 in
  • Weight
    67.25 lbs
Details
  • Finish
    Dampers: Yellow/Springs: Blue
  • Internal Design
    Twintube
  • PartType
    Suspension Kit
  • Segment
    Tuning
  • Series
    B14 (PSS)
  • Title
    Bilstein Shock Absorbers
Manufacturer description
  • Manufacturer Label
    B14 (PSS)

 Fast Shipping and Easy Returns


Customer satisfaction is our top priority. We want to ensure your experience with BuyBrakes.com is the best it can possibly be. If you're unsatisfied with your order and wish to return it, please follow our guidelines below.

Compatible with the following vehicles

Model Engine Trim Notes
2023, Fiat 500X Pop Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2023, Fiat 500X Sport Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2022, Fiat 500X Pop Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2022, Fiat 500X Sport Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2022, Fiat 500X Trekking Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2021, Fiat 500X Pop Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2021, Fiat 500X Sport Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2021, Fiat 500X Trekking Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2021, Fiat 500X Trekking Plus Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2020, Fiat 500X Pop Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2020, Fiat 500X Sport Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2020, Fiat 500X Trekking Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2020, Fiat 500X Trekking Plus Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2019, Fiat 500X Pop Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2019, Fiat 500X Trekking Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2019, Fiat 500X Trekking Plus Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2018, Fiat 500X Lounge, AWD Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2018, Fiat 500X Pop, AWD Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2018, Fiat 500X Sport, AWD Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2018, Fiat 500X Trekking, AWD Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2018, Fiat 500X Urbana, AWD Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2017, Fiat 500X Lounge, AWD Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2017, Fiat 500X Pop, AWD Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2017, Fiat 500X Sport, AWD Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2017, Fiat 500X Trekking, AWD Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2017, Fiat 500X Urbana, AWD Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2016, Fiat 500X Easy, AWD Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2016, Fiat 500X Lounge, AWD Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2016, Fiat 500X Sport, AWD Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2016, Fiat 500X Trekking, AWD Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
2016, Fiat 500X Trekking Plus, AWD Front and Rear, Front Lowered Height: 20-40mm, up to 1150kg Axle Load;Rear Lowered Height: 20-40mm, up to 1000kg Axle Load
